500V DC Fuse Types General Purpose Fuses Stud Mount Assembling For EV / HEV

500V DC Fuse Types General Purpose Fuses Stud Mount Assembling For EV / HEV

500V DC Fuse Types General Purpose Fuses Stud Mount Assembling For EV / HEV

Product Details:

Place of Origin: China
Brand Name: Julun
Certification: CE/UL/VDE/KC/ROHS
Model Number: EV1845

Payment & Shipping Terms:

Minimum Order Quantity: 100 / Negotiable
Price: Negotiable
Packaging Details: Standard carton
Delivery Time: 7~10 Working days
Payment Terms: L/C, D/P, T/T, MoneyGram
Supply Ability: 10000/Piece/Weekly
Contact Now
Detailed Product Description
Usage: Automotive Breaking Capacity: High
Safety Standards: IEC Maximum Voltage: 500VDC
Assembling: Stud Mount

Ceramic Automotive 500VDC General Purpose Fuse for EV / HEV



EV1845 Series.pdf



Description



General pupose fuses for EV/HEV

Stud‐mount, optional for other installtion

500Vdc ideal for EV or HEV application

Execllent DC performance

Special designed fuse base for vehicle situation



Electrical Characteristics
% of Ampere Operating
Rating (A) Min Max
110% 14400
250% 0.5 100
300% 0.1 15
500% 1




Specifications



Type Ordering P/N Electrical Characteristics
Rated Current (Amp) Interrupting rating Energy Integrals I2t (A2S)
Pre‐Arcing Clearing at 500V
Monomer EV1845-20 20 500Vdc/2000A 120 420
EV1845-25 25 180 660
EV1845-32 32 300 1100
EV1845-35 35 360 1300
EV1845-40 40 490 1710
EV1845-50 50 760 2600
EV1845-60 60 1100 3800
EV1845-70 70 1500 5200
EV1845-80 80 2000 6800
EV1845-100 100 3100 11000
EV1845-125 125 4600 16000
EV1845-150 150 6800 26000
Double splicing EV1845-175 175 9200 37800
EV1845-200 200 12500 48500
EV1845-225 225 15000 61500
EV1845-250 250 18000 75200
EV1845-300 300 27300 112000


Typical Pre‐arching I2t are measured at 10In Current



Dimension



500V DC Fuse Types General Purpose Fuses Stud Mount Assembling For EV / HEV

                   Monomer                                                    Double splicing











FAQ


Q: What can i do if i got a broken product form A-TEAM FUSE INC?
A: First of all please tell us as soon as possible after we will send a new one to you immediately

but please send the broken product to us .you don't have to worry about the carriage charge we will

pay for that.
Q;Are we a importer or manufacturer?
A;We are a manufacturer
Q:Why you have to choose us
A:High quality assurance. The most competitive price and fast shipping


Please tell me:
What product specifications do you need? when you ask for a quotation.I will give you the most

competitive price per as your requirements. And we have many types for you to choose.


P.S.:If you can't find any products to meet your requirements. welcome to send us the details

drawings so that we can provide us our professional & best service to you.
