Miniature 1140 Series Chip 500a 125v Fuse Slow Blow Low Voltage Circuit Protection

Miniature 1140 Series Chip 500a 125v Fuse Slow Blow Low Voltage Circuit Protection
Miniature 1140 Series Chip 500a 125v Fuse Slow Blow Low Voltage Circuit Protection

Large Image :  Miniature 1140 Series Chip 500a 125v Fuse Slow Blow Low Voltage Circuit Protection Get Best Price

Product Details:
Place of Origin: CHINA
Brand Name: Julun
Certification: CE/UL/VDE/KC/ROHS
Model Number: 487
Payment & Shipping Terms:
Minimum Order Quantity: 100 / Negotiable
Price: Negotiable
Packaging Details: Standard carton
Delivery Time: 7~10 Working days
Payment Terms: L/C, D/P, T/T, MoneyGram
Supply Ability: 10000/Piece/Weekly
Detailed Product Description
Materials: Ceramics Operating Temperature: -55℃ To +125℃
Storage Conditions: +10℃ To +60℃ Time Current Characteristics: Slow Fuse (T)
Breaking Ability: 500A@125Vac, 1000A@72Vdc Authentication Through: CURus, VDE, CQC, PSE, KC, TUV
High Light:

slow blow micro fuse

,

mini cartridge fuse

Miniature 1140 Series Chip 500a 125v Fuse Slow Blow Low Voltage Circuit Protection



OC_487_datasheet.pdf



Main Characteristics
Brick fuse; Time-Lag(T)
Standard
UL-248-1
Materials
Body: Ceramic
End Caps: Copper plated with silver
Operating Temperature
-55℃ to +125℃
Stock Temperature
+10℃ to +60℃
Relative humidity:≤75% yearly average
Without dew, maximum 30 days at 95%
Vibration Resistance
24 cycles at 15 min. each (60068-6)
10-60Hz at 0.75mm amplitude
60-2000Hz at 10g acceleration
Soldering Parameters
260℃.≤10 sec (Wave Soldering)
300℃.≤2 sec (Hand Soldering)
Soldering Peak:
260℃. 10 sec.
280℃. 5 sec. (IEC 60068-20)



Time vs Current Characteristics: UL-248-14
Rated Current 100% 200%
80A-100A >4H <10s



Electrical Characteristics



Amp Code Rated Current Rated Voltage Breaking Capacity Cold Resistance (mΩ) Typical Melting I²t(A²sec)
2800 80A 72V/63V/32VDC 125VAC 1000A@72/63/32V DC 500A@125V AC 0.47 1700
3100 100A 0.3 4000



* AC Interrupting Rating (Measured at designated voltage, 100% power factor random closing)

* DC Interrupting Rating (Measured at designated voltage, time constant of less than 50 microseconds, battery source)

* Typical Pre-arcing I2 t are measured at 10In Current, DC battery bank, but not exceeding the interrupting rating, time constant of calibrated circuit less than 50 microseconds)

* High lead immunity products



Dimension



Miniature 1140 Series Chip 500a 125v Fuse Slow Blow Low Voltage Circuit Protection 0
