Industrial Grade Photovoltaic Fuse 1000V DC 15A High Voltage Rating 1500V DC 40A DC
Product Details:
| Place of Origin: | China |
| Brand Name: | JULUN |
| Certification: | IEC UL VDE CCC |
| Model Number: | YR RT |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 |
|---|---|
| Price: | 2~5USD |
| Packaging Details: | carton |
| Delivery Time: | 1~2weeks |
| Payment Terms: | T/T |
| Supply Ability: | 100000PCS/day |
|
Detail Information |
|||
| Be Suitable For: | Photovoltaic Bus Box, Photovoltaic Module Protection | Fuse Element Material: | Silver/Copper/silica/ |
|---|---|---|---|
| Fuse Size: | 10x38mm,14x51mm,14x65mm, 10x85mm | Fuse Shepe: | Cylindrical Fuse |
| Weight: | 20g | Working Temperature: | -50~105°C |
| Rated Current: | 10A 12A 15A 16A 20A 25A 30A 32A 40A 50A 63A | Use For: | Solar Photovoltaic Inverter |
| High Light: | Industrial Grade Photovoltaic Fuse,1000V DC Photovoltaic Fuse |
||
Product Description
Photovoltaic Fuse Industrial Grade 1000VDC 15A F With High Voltage Rating 1500VDC 40A DC
Product Description:
Solar PV Fuse is a high voltage solar fuse designed to provide reliable protection for solar photovoltaic systems. It has a rated current of 10A, 12A, 15A, 16A, 20A, 25A, 30A, 32A, 40A, 50A, 63A and a rated voltage of 1000VDC and 1500VDC. This product features a 10*38mm gPV 1000VDC 32A FUSE with a ceramic fuse body material and a weight of 20g. It is certified by TUV and CE. Solar PV Fuse is designed for use in photovoltaic systems, providing reliable protection for solar photovoltaic systems. It is the perfect solution for all photovoltaic system applications.
Features:
- Product Name: Solar PV Fuse
- Be suitable for: Photovoltaic Bus Box, Photovoltaic Module Protection
- Standart: IEC60269.6
- Rated Current: 10A 12A 15A 16A 20A 25A 30A 32A 40A 50A 63A
- Rated Voltage: 1000VDC 1500VDC
- Breaking capacity: 30kA
- Cylindrical 14*51mm 25A 1500VDC solar system fuse and fuse holder
- DIN rail solar fuse holder
- Cylindrical 14*51mm 25A 1500VDC solar system fuse and fuse holder
Technical Parameters:
| Item | Solar PV Fuse |
|---|---|
| Weight | 20g |
| Fuse Body Material | Ceramic |
| Standart | IEC60269.6 |
| Fuse Size | 10x38mm,14x51mm,14x65mm, 10x85mm |
| Use For | Solar Photovoltaic Inverter |
| Product Name | Solar PV Fuse Holder With Fuse |
| Rated Voltage | 1000VDC 1500VDC |
| Fuse Element Material | Silver/Copper/silica/ |
| Rated Current | 10A 12A 15A 16A 20A 25A 30A 32A 40A 50A 63A |
| Breaking capacity | 30kA |
| Keywords | 10*38mm gPV 1000VDC 32A FUSE, High voltage solar fuse, DIN rail solar fuse holder |
Applications:
Solar PV Fuse, produced by JULUN, is a cylindrical fuse with model number YR RT, and is made in China. It is a 10*38mm gPV 1000VDC 32A FUSE. With a rated current of 10A, 12A, 15A, 16A, 20A, 25A, 30A, 32A, 40A, 50A and 63A, and a rated voltage of 1000VDC and 1500VDC, it is suitable for photovoltaic bus box and photovoltaic module protection. Weighing only 20g, this fuse features high voltage and excellent performance, being an ideal choice for photovoltaic applications. This eramic photovoltaic fuse 10*85 1500DC is also known as high voltage solar fuse, and is produced by JULUN YR RT.
Customization:
Solar PV Fuse
JULUN YR RT Solar PV Fuse is built to IEC60269.6 standard and manufactured in China. Rated voltage of 1000VDC or 1500VDC, fuse body material is ceramic, size are 10x38mm, 14x51mm, 14x65mm, 10x85mm, installation mode is Din Guide Fuse Holder. It is TUV CE certified and suitable for marine solar fuse.
Support and Services:
We provide support and service for Solar PV Fuse, a product designed to protect solar photovoltaic panels from over-current and short-circuit damage. Our technical support team is available to answer any questions you may have about the product and its installation and maintenance.
Our service team offers a range of maintenance and repair services for Solar PV Fuse, including:
- Inspection and testing of the fuse and its connections
- Replacement of damaged or faulty components
- Cleaning and lubrication of connectors and terminals
- Troubleshooting of any electrical issues
- Advice on installation and maintenance of the product
We are committed to providing excellent customer service and are available to answer any questions you may have about Solar PV Fuse. Contact us today to find out more about our technical support and service.
Packing and Shipping:
Solar PV Fuses are packed in a high-quality cardboard box with an anti-static inner bag. The box is labeled with product details and the customer's specific requirements. The boxes are then shrink-wrapped to ensure safe delivery to the customer.
We use reliable carriers for all our shipping needs. The packages are shipped to the customer's door with tracking information provided. We also provide express shipping for urgent orders.
FAQ:
- Q: What is the brand name of the Solar PV Fuse?
- A: The brand name of the Solar PV Fuse is JULUN.
- Q: What is the Model Number of the Solar PV Fuse?
- A: The Model Number of the Solar PV Fuse is YR RT.
- Q: Where is the Solar PV Fuse made?
- A: The Solar PV Fuse is made in China.
- Q: What is the purpose of a Solar PV Fuse?
- A: A Solar PV Fuse is an electrical device designed to protect an electrical circuit from an overload or short circuit.
- Q: What are the features of the Solar PV Fuse?
- A: The Solar PV Fuse has features such as high-temperature resistance, arc extinguishing, high breaking capacity, and reliable performance.
