660 VAC / DC 6x32mm High Voltage Fuse HV640 Series Quick Acting Fuse

China 660 VAC / DC 6x32mm High Voltage Fuse  HV640 Series Quick Acting Fuse supplier

Large Image :  660 VAC / DC 6x32mm High Voltage Fuse HV640 Series Quick Acting Fuse

Product Details:

Place of Origin: CHINA
Brand Name: Julun
Certification: CE/UL/VDE/KC/ROHS
Model Number: HV640

Payment & Shipping Terms:

Minimum Order Quantity: 100 / Negotiable
Price: Negotiable
Packaging Details: Standard carton
Delivery Time: 7~10 Working days
Payment Terms: L/C, D/P, T/T, MoneyGram
Supply Ability: 10000/Piece/Weekly
Contact Now
Detailed Product Description
Rated Voltage: 600VAC / DC Rated Current: 15A ~ 30A
Dimension: 6*32mm Material: Ceramic
Breaking Capacity: Fast

660 VAC / DC 6x32mm High Voltage Fuse  HV640 Series Quick Acting Fuse



hv640_revx.pdf



Description



Fast Acting, high breaking capacity under 660V
Special Engineering Material tube, Silver plated cap construction
High breaking capacity for high energy application
RoHS and Lead Free material



Electrical Characteristics
2.0In  5 minutes, Maximum
3.0In 10 Seconds, Maximum



Specifications



Part No. Rated Voltage(V) Rated Current Breaking Capacity (A) Typical Cold.
Resistance
(mOhms)

TypicalPre-Arcing

I2t(A2Sec)

HV640.15 660V AC/DC 15 1000 7.3 66
HV640.16 16 7.3 62
HV640.20 20 5.5 120
HV640.25 25 4.6 200
HV640.30 30 3.7 270

* DC Cold Resistance are measured at <10% of rated current in ambient temperature of 25℃
* Typical Pre-arcing I2t are measured at 10In Current



Dimension



660 VAC / DC 6x32mm High Voltage Fuse  HV640 Series Quick Acting Fuse
