IP65 1500V 40A Quick Fire Safety Switch Roof Electric Photovoltaic Solar Panel
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | JULUN |
| Model Number: | TW-RSD150-40-4 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10PCS |
|---|---|
| Packaging Details: | 10 |
| Delivery Time: | 4-6 weeks |
| Payment Terms: | T/T |
| Supply Ability: | 1,000,00 PCS |
|
Detail Information |
|||
| Certification: | CE | Strings: | 1~10 Strings Available |
|---|---|---|---|
| Rated Voltage: | Up To 1500V | Rated Current: | 40A |
| Protection: | IP65 PROTECTION And Anti UV | Control: | APP Remote Control |
| Signal: | Shutdown Feedback SIGNAL | Auto: | Auto Shutdown Exceeding 70°C |
| Life: | 1000 MECHANICAL LIFE CYCLES | Isolator With: | CE,CB,TUV,SAA |
| High Light: | Photovoltaic RSD Fire Safety Switch,IP65 40A Fire Safety Switch,APP Firefighter Safety Switch |
||
Product Description
IP65 1500V 40A Quick Switch Roof Photovoltaic Factory Solar Panel Electric Fire Safety Switc
01 What is Rapid Shutdown (RSD)?
Rapid Shutdown (RSD) is the concept of photovoltaic power station safety protection proposed by the National Electrical Code (NEC) of the United States.
In some countries, including Australia, Germany and the United States, with the increase in photovoltaic systems, more and more firefighters are requiring the installation of "fire switches" to reduce the risk of electric shock when operating in photovoltaic systems.
As early as 2014, the United States published the NEC2014 690.12 "component-level self-shutdown solutions" standard, which requires rapid shutdown of photovoltaic systems.
Photovoltaic systems must be capable of quick shut-off in accordance with the NEC690.12-2017 regulation. With the distance to the photovoltaic matrix 305mm as the limit, within 30 seconds after the quick turn-off device starts, the voltage outside the limit range is reduced to below 30V, and the voltage within the limit range is reduced to below 80V, which requires the realization of "component-level turn-off".
02
Why is rapid Turn-off (RSD) important?
Due to the photovoltaic system is electrically charged equipment, power voltage is higher, and the equipment and circuit current always exist, the photovoltaic system in the fire accident in the past, even shut down the grid power supply, and the inverter automatically closed, from components to the inverter wire still charged or controller, dc high voltage to the personal safety is a huge hidden trouble.
In case of emergency, the quick shutdown (RSD) function reduces the component voltage to the safe voltage, realizing the quick shutdown of the component level, providing higher personal safety protection for the owner, installation operation and maintenance personnel, and firefighters.
