Cylindrical Solar System Fuse And Fuse Holder 14*51mm 25A 1500VDC
Product Details:
| Place of Origin: | China |
| Brand Name: | JULUN |
| Certification: | IEC UL VDE CCC |
| Model Number: | YRPV30 /40 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 |
|---|---|
| Price: | 20~30 |
| Packaging Details: | carton |
| Delivery Time: | 1~2weeks |
| Payment Terms: | T/T |
| Supply Ability: | 100000PCS/day |
|
Detail Information |
|||
| Fuse Body Material: | Ceramic | Fuse Element Material: | Silver/Copper |
|---|---|---|---|
| Rated Current: | 30A 40A | Rated Voltage: | 1500VDC |
| Be Suitable For: | Photovoltaic Bus Box, Photovoltaic Module Protection | Fuse Size: | 5x20mm 10x38mm 14x51mm 10X85mm |
| Breaking Capacity: | 25kA | Product Name: | Solar PV Fuse |
| High Light: | Cylindrical Solar System Fuse,14*51mm Solar System Fuse,1500VDC Solar Fuse |
||
Product Description
Product Description:
Solar PV Fuse is a cylindrical-shaped fuse with 4 different sizes including 5x20mm, 10x38mm, 14x51mm and 10X85mm, which is designed for solar power systems. It is made of silver/copper element and ceramic body and can be used in the rated current range from 20A to 100A.
This solar fuse is UL recognized and widely used in different kinds of solar energy systems, such as high voltage solar fuse, marine solar fuse and solar system fuse and fuse holder. The cylindrical 14*51mm 25A 1500VDC solar system fuse and fuse holder is one of the most popular products.
Solar PV Fuse has the features of high quality, high reliability, high anti-interference capability and high impact strength, which makes it popular in the solar industry.
It is certified with UL and ROHS standard and has been exported to more than 30 countries and regions.
Features:
- Product Name: Solar PV Fuse
- Fuse Size: 5x20mm 10x38mm 14x51mm 10X85mm
- Fuse Element Material: Silver/Copper
- Fuse Body Material: Ceramic
- Rated Current: 20A-100A
- Breaking capacity: 25kA
- Marine solar fuse
- Cylindrical 14*51mm 25A 1500VDC solar system fuse and fuse holder
- Ceramic photovoltaic fuse 10*85 1500DC
Technical Parameters:
| Attribute | Value |
|---|---|
| Product Name | Solar PV Fuse |
| Rated Current | 10A-40A |
| Fuse Size | 14x51mm |
| Rated Voltage | 1500VDC |
| Fuse Body Material | Ceramic |
| Fuse Element Material | Silver/Copper |
| Breaking capacity | 25kA |
| Be suitable for | Photovoltaic Bus Box, Photovoltaic Module Protection |
Applications:
Product code |
Rated curren |
|
Safety certificate | Power loss 1.0In(W) |
Net weigh |
|||||||||
| △ | (E | |||||||||||||
| YRPV40/10NF | 10A | 1500Vdc TUV&CE:25kA |
● | ● | 0 | 1.7 | 24.5g | |||||||
| YRPV40/12NF | 12A | ● | 0 | 2.0 | ||||||||||
| YRPV40/15NF | 15A | 0 | 2.5 | |||||||||||
| YRPV40/20NF | 20A | o | 3.0 | |||||||||||
| YRPV40/25NF | 25A | 3.9 | ||||||||||||
| YRPV40/32NF | 32A | o | 5.0 | |||||||||||
| YRPV40/40NF | 40A | o | 6.3 | |||||||||||
| YRPV40NF | 10-40A | 1000Vdc:25kA | 0 | 0 | 6.3 | |||||||||
JULUN YRPV15 Solar PV Fuse is a 10*38mm gPV 1000VDC rated fuse with a rated current of 20A-100A. It is a UL 2579 and UL 2580 listed product, which is TUV CE certified and designed for photovoltaic bus box and photovoltaic module protection. The fuse element material is silver/copper with a breaking capacity of 25kA, and it is suitable for solar panel thermal fuse.
Customization:
We would like to present our Solar PV Fuse, JULUN YRPV15, from China. This product comes with a wide variety of fuse sizes, ranging from 5x20mm to 10x85mm. It is certified with TUV CE and has a breaking capacity of up to 25kA. The fuse element is made of either silver or copper.
The product is rated for currents between 20A and 100A. Additionally, 10*38mm gPV 1000VDC 32A FUSE is also available.
Support and Services:
We provide comprehensive technical support and service for our Solar PV Fuse products. Our knowledgeable team of engineers, technicians, and customer service representatives are available to answer your questions 24/7.
Our team is highly skilled in troubleshooting and resolving any issues that may arise with our Solar PV Fuse products. We also provide a variety of services such as installation assistance, product customization, and maintenance.
We strive to provide the highest quality technical support and service for our Solar PV Fuse products. We are committed to providing the best possible experience for our customers.
Packing and Shipping:
Solar PV Fuse Packaging and Shipping:
For safety reasons, the Solar PV Fuse should be packed carefully in a box with adequate padding to prevent any possible damage during shipping. The box should be sealed with adhesive tape.
When shipping the Solar PV Fuse, it is recommended to use a reliable courier service to ensure that the product reaches its destination safely and on time. It is also important to make sure that the package is clearly labeled with the address of the destination.
FAQ:
Q1: What is Solar PV Fuse?
A1: Solar PV Fuse is a device produced by JULUN with Model Number YRPV15, which is used to protect solar photovoltaic system from over-current or short circuit. It is made in China.
Q2: What is the rated voltage of JULUN Solar PV Fuse?
A2: JULUN Solar PV Fuse has a rated voltage of up to 1000V.
Q3: What is the rated current of JULUN Solar PV Fuse?
A3: JULUN Solar PV Fuse has a rated current of up to 40A.
Q4: What is the breaking capacity of JULUN Solar PV Fuse?
A4: JULUN Solar PV Fuse has a breaking capacity of up to 6kA.
Q5: What is the material of JULUN Solar PV Fuse?
A5: JULUN Solar PV Fuse is made of high-grade copper and zinc alloy.
