50A 63VDC Electric Vehicle Fuse With Mall And High Current Rating For Short Circuit Protection
Product Details:
| Place of Origin: | China |
| Brand Name: | JULUN |
| Certification: | CE UL CCC |
| Model Number: | A121601 50~350A 63~125VDC |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 |
|---|---|
| Price: | 3~6USD |
| Packaging Details: | Carton |
| Delivery Time: | 2~4weeks |
| Payment Terms: | T-T |
| Supply Ability: | 1000K/PCS |
|
Detail Information |
|||
| Net: | 15g | Package: | Carton Box |
|---|---|---|---|
| Certificate: | RoHS Compliant And Lead Free | Application: | Automotive,Motorcycles, Power Tools, Ships, Electrical Equipment, Industrial Equipment, Medical Equipment |
| Breaking Capacity: | 63Vdc/8kA * 100Vdc/6KA * 125Vdc/3KA | Temperature Range: | -40℃~125℃ |
| Appearance Features:: | Mall Size With High Current Rating For Short Circuit Protection | Recommended Tight Torque:: | M6: 5-5.5N·m ; M5: 3.5-4N·m |
| High Light: | 63VDC Electric Vehicle Fuse,50A auto fuses,RoHS Compliant auto fuses |
||
Product Description
Product Description:
Electric Vehicle Fuse is a reliable and efficient product, designed for 7KW charger, home EV charger for electric car, DC electric car charging. It has a recommended tight torque of M6: 5-5.5N·m and M5: 3.5-4N·m, a net weight of 15g, and a temperature range of -40℃~125℃. It is packaged in a carton box and is rated for 63VDC, 100VDC and 125VDC. It is ideal for electric car charging station and EV charging system, providing safe and reliable charging experience.
- Product Name: Electric Vehicle Fuse
- Size: 6*32mm, Can Bring Leads
- Temperature Range: -40℃~125℃
- certificate: RoHS Compliant And Lead Free
- Application: Automotive,Motorcycles, Power Tools, Ships, Electrical Equipment, Industrial Equipment, Medical Equipment
- 7KW Charger, home ev charger For Electric Car, Electric Vehicle Fast Charging
Technical Parameters:
| Parameter | Value |
|---|---|
| Size | 6*32mm, Can Bring Leads |
| Net | 15g |
| Breaking Capacity | 63Vdc/8kA * 100Vdc/6KA * 125Vdc/3KA |
| Recommended Tight Torque | M6: 5-5.5N·m ; M5: 3.5-4N·m |
| Material | Silver Plate,Copper,Ceramic, Quartz Sand |
| Certificate | RoHS Compliant And Lead Free |
| Application | Automotive,Motorcycles, Power Tools, Ships, Electrical Equipment, Industrial Equipment, Medical Equipment |
| Rated Current | 50A 60A 80A 100A 150A 200A 250A 300A 250A |
| Apply To | Automobiles, Batteries, Electrical Machinery, Ships, Motorcycles, Equipment, And Other Products |
| Package | Carton Box |
Applications:
JULUN Electric Vehicle Fuse has a wide range of applications, providing reliable protection for automobiles, batteries, electrical machinery, ships, motorcycles, equipment, and other products. With a temperature range of -40℃~125℃ and rated current of 50A to 350A, it can be used in 7KW chargers, portable EV chargers, and 22KW chargers. The size of JULUN Electric Vehicle Fuse is 6*32mm, and it can also bring leads. It is CE UL CCC certified, RoHS compliant and lead-free, and the minimum order quantity is 100. The price range is 3~6 USD per piece, and the delivery time is 2~4 weeks. Payment terms are T/T, and the supply ability is 1000K/PCS per month. The package for JULUN Electric Vehicle Fuse is carton.
Customization:
- Brand Name: JULUN
- Model Number: A121601 50~350A 125VDC
- Place of Origin: China
- Certification: CE UL CCC
- Minimum Order Quantity: 100
- Price: 3~6USD
- Packaging Details: Carton
- Delivery Time: 2~4weeks
- Payment Terms: T-T
- Supply Ability: 1000K/PCS
- Rated Current: 50A 60A 80A 100A 150A 200A 250A 300A 250A
- Size: 6*32mm, Can Bring Leads
- Rated Voltage: 63VDC 100VDC 125VDC
- Product Name: Electric Vehicle Fuse
- Net: 15g
Keywords:
- Automotive battery charger
- CCS EV Charger
- portable EV charger
Support and Services:
We offer technical support and service for our Electric Vehicle Fuse product. Here are some of the services that we provide:
- 24/7 technical assistance via phone or email
- On-site installation and maintenance services
- Troubleshooting and repair services
- Software and firmware updates
If you have any questions or need assistance with your Electric Vehicle Fuse product, please don't hesitate to contact us.
