Solar PV Fuse Holder 10*38mm 32A 1000VDC
Product Details:
| Place of Origin: | China |
| Brand Name: | Photovoltaic fuse holder |
| Certification: | IEC60947-3 IEC60292 |
| Model Number: | TSA1038 10*38mm DN56411 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100PCS |
|---|---|
| Price: | 2~4.5USD |
| Packaging Details: | Carton Box |
| Delivery Time: | 2-3WEEKS |
| Payment Terms: | TT |
| Supply Ability: | 1000KPCS |
|
Detail Information |
|||
| Rated Operational Voltage: | DC1000V | Utilization Category: | DC-PV0 |
|---|---|---|---|
| Rated Operational Current Ie: | 32A | Fuse Link Size: | 10*38 |
| Name And Discription: | Discription PV(Photovoltaic) Fuse Holders(Disconnectors) | Rated Impulse Withstand Voltage Uimp: | 6 KV |
| Conductor Area: | 0.75-25mm2 | Breaking Capacity With Fuse: | 20kA |
| Highlight: | Solar PV Fuse Holder 10x38mm,32A Solar PV Fuse Holder,1000VDC Solar Fuse Holder |
||
Product Description
The Solar PV Fuse product is a crucial component designed specifically for Photovoltaic systems. This product includes PV Fuse Holders (Disconnectors) that play a vital role in the safety and efficiency of solar installations.
With a degree of protection rated at IP20, the Solar PV Fuse is suitable for indoor use and provides adequate protection against solid objects larger than 12.5mm in size.
Featuring a conductor area ranging from 0.75mm² to 25mm², this product accommodates various wire sizes commonly used in solar panel installations, ensuring compatibility with a wide range of systems.
The Solar PV Fuse boasts a high breaking capacity of 20kA when used with the appropriate fuse. This ensures the fuse can safely and effectively protect the system in the event of a fault or overcurrent.
Designed to work seamlessly with a 10*38mm fuse link, the Solar PV Fuse product is optimized for use with cylindrical 14*51mm fuses commonly found in solar systems. This compatibility ensures efficient operation and easy replacement when necessary.
For added convenience and versatility, the Solar PV Fuse is equipped with a DIN rail solar fuse holder, allowing for easy installation and secure mounting within the solar system setup. This feature simplifies maintenance tasks and ensures the fuse is easily accessible when needed.
With a rating of 1000VDC and a current capacity of 15A, the Solar PV Fuse is well-suited for use in solar applications, providing reliable protection and performance for solar panels and related components.
- Product Name: Solar PV Fuse
- Degree of protection: IP20
- Breaking capacity with fuse: 20kA
- Rated impulse withstand voltage Uimp: 6 KV
- Name and Description: Description PV(Photovoltaic) Fuse Holders(Disconnectors)
- (Reference) Standard: IEC 60947-3, GB/T14048.3
- Keywords: High voltage solar fuse, TUV CE
| Rated impulse withstand voltage Uimp | 6 KV |
| (Reference)Standard | IEC 60947-3, GB/T14048.3 |
| Name and Description | Description PV(Photovoltaic) Fuse Holders(Disconnectors) |
| Breaking capacity with fuse | 20kA |
| Conductor area | 0.75-25mm² |
| Degree of protection | IP20 |
| Mounting method | DIN Rail Installation |
| Fuse link size | 10*38 |
| Utilization category | DC-PV0 |
| Rated operational current Ie | 32A |
The Photovoltaic fuse holder, model number TSA1038 10*38mm, is a high-quality solar PV fuse designed for various application occasions and scenarios. Manufactured in China, this product comes with certifications such as IEC60947-3 and IEC60292, ensuring its reliability and safety.
One of the key product attributes is its rated operational voltage of DC1000V, making it suitable for use in solar PV systems. The fuse holder is designed for utilization category DC-PV0, providing protection and safety in solar installations. Its mounting method using DIN Rail Installation allows for easy and secure placement in different setups.
The 10*38mm gPV 1000VDC 32A fuse is ideal for marine solar applications, offering reliable protection in harsh environments. Whether used in solar panels on boats or other marine vessels, this fuse holder ensures the safety of the system.
With a minimum order quantity of 100PCS and a price range of 2~4.5USD, the Photovoltaic fuse holder is cost-effective for both small-scale and large-scale solar projects. The packaging details in a Carton Box and delivery time of 2-3 weeks cater to the convenience of customers.
Payment terms for this product are TT, and the supply ability is 1000KPCS, ensuring availability for various project sizes. The degree of protection of IP20 and compliance with standards such as IEC 60947-3 and GB/T14048.3 further highlight the quality and reliability of this solar PV fuse holder.
Product Customization Services for the Solar PV Fuse product:
- Brand Name: Photovoltaic fuse holder
- Model Number: TSA1038 10*38mm
- Place of Origin: China
- Certification: IEC60947-3 IEC60292
- Minimum Order Quantity: 100PCS
- Price: 2~4.5USD
- Packaging Details: Carton Box
- Delivery Time: 2-3WEEKS
- Payment Terms: TT
- Supply Ability: 1000KPCS
- Utilization category: DC-PV0
- Mounting method: DIN Rail Installation
- Rated impulse withstand voltage Uimp: 6 KV
- Conductor area: 0.75-25mm²
- Breaking capacity with fuse: 20kA
The Product Technical Support and Services for the Solar PV Fuse product include:
- Assistance with product installation and setup
- Troubleshooting and diagnosis of any issues related to the fuse
- Guidance on proper maintenance and care of the fuse
- Information on product specifications and compatibility
Product Packaging:
The Solar PV Fuse is carefully packaged in a sturdy cardboard box to ensure safe delivery. The product is securely wrapped in bubble wrap to prevent any damage during transportation.
Shipping:
We offer fast and reliable shipping for the Solar PV Fuse product. Orders are typically dispatched within 1-2 business days and are shipped via trusted carriers to ensure timely delivery to your doorstep.
