Auto Fuses 30-70A, 65-68mV Voltage Drop, Tin plated Copper Terminal
Product Details:
| Place of Origin: | China |
| Brand Name: | Julun |
| Certification: | CE/UL/VDE/KC/ROHS |
| Model Number: | CP |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 / Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard carton |
| Delivery Time: | 7~10 Working days |
| Payment Terms: | L/C, D/P, T/T, |
| Supply Ability: | 10000/Piece/Weekly |
|
Detail Information |
|||
| Interrupting Rating: | 40A~400A | Voltage Rating: | 12V-24V |
|---|---|---|---|
| Operating Temperature Range: | -40˚C To + 125˚C | Housing: | Transparent Nylon Composite |
| Terminal: | Tin Plated Copper | Mounting Torque M5: | 4.5 Nm +/- 1Nm |
| Complies With: | ISO 8820-5 | Application: | Automotive, Marine, Industrial |
| Brand: | OEM/ODM | Breaking Capacity: | 6000A |
| Color: | Red, Blue, Yellow, Green, White, Black | Current Rating: | 2A-30A |
| Material: | Copper, Zinc Alloy | Operating Temperature: | -40℃~+125℃ |
| Package: | Carton Box, Plastic Bag | Product Name: | Automotive Blade Fuses |
| Size: | Standard Size | Warranty: | 1 Year |
| High Light: | mini blade car fuses,car blade fuses,1000 Amp Bolt In Car Blade Fuse |
||
Product Description
Abf-199-1. g See Larger Imageabf-199-1. g Bolt In Auto Blade Automotive Fuses (FBELE)
Standard Auto fuse
Auto fuses in Gold or Nickel plated
Fuse types:MAXI/AGU/ANL/MINI-ANL fuses are optional
We will send you sample for your quality testing before your order
AMP# are optional for different types,20-300AMP
Interrupting Rating: 1000A @ 58 VDC
Voltage Rating: 32/48/58 VDC
Operating Temperature Range: -40˚C to + 125˚C
Housing: Transparent Nylon Composite
Terminal: Tin plated Copper
Mounting Torque M5: 4.5 Nm +/- 1Nm
Complies with: ISO 8820-5
UL 248 Special Purpose Fuses
| % of Rating | Opening Time Min / Max (s) | |
| 30-125A | 150-200A | |
| 75 | – / – | 360,000 s / – |
| 100 | 360,000 s / – | – / – |
| 110 | 14,400 s / – | – / – |
| 150 | 90 s / 3,600 s | – / – |
| 200 | 3 s / 100 s | 1 s / 15 s |
| 300 | 0.3 s / 3 s | – / – |
| 350 | – / – | 0.3 s / 5 s |
| Part Number | Current Rating | Typ. Voltage Drop | Cold Resistance | I2t |
| FKYANS/ANM-030 | 30 A | 65 mV | 2.06 mΩ | 4200 |
| FKYANS/ANM-040 | 40 A | 65 mV | 1.398 mΩ | 10000 |
| FKYANS/ANM-050 | 50 A | 65 mV | 1.025 mΩ | 13000 |
| FKYANS/ANM-060 | 60 A | 68 mV | 0.865 mΩ | 21700 |
| FKYANS/ANM-070 | 70 A | 70 mV | 0.72 mΩ | 24000 |
| FKYANS/ANM-080 | 80 A | 58 mV | 0.541 mΩ | 24600 |
| FKYANS/ANM-100 | 100 A | 60 mV | 0.457 mΩ | 51300 |
| FKYANS/ANM-125 | 125 A | 71 mV | 0.394 mΩ | 73200 |
| FKYANS/ANM-150 | 150 A | 77 mV | 0.323 mΩ | 81900 |
| FKYANS/ANM-175 | 175 A | 77 mV | 0.285 mΩ | 100000 |
| FKYANS/ANM-200 | 200 A | 77 mV | 0.261 mΩ | 125000 |
Q: What can i do if i got a broken product form A-TEAM FUSE INC?
A: First of all please tell us as soon as possible after we will send a new one to you immediately
but please send the broken product to us .you don't have to worry about the carriage charge we will
pay for that.
Q;Are we a importer or manufacturer?
A;We are a manufacturer
Q:Why you have to choose us
A:High quality assurance. The most competitive price and fast shipping
Please tell me:
What product specifications do you need? when you ask for a quotation.I will give you the most
competitive price per as your requirements. And we have many types for you to choose.
P.S.:If you can't find any products to meet your requirements. welcome to send us the details
drawings so that we can provide us our professional & best service to you.
