• KLQ Series - 600V 6A Enhanced Time Delay Miniature Fuse High Voltage Fuse
KLQ Series - 600V 6A Enhanced Time Delay Miniature Fuse High Voltage Fuse

KLQ Series - 600V 6A Enhanced Time Delay Miniature Fuse High Voltage Fuse

Product Details:

Place of Origin: CHINA
Brand Name: Julun
Certification: CE/UL/VDE/KC/ROHS
Model Number: KLQ

Payment & Shipping Terms:

Minimum Order Quantity: 100 / Negotiable
Price: Negotiable
Packaging Details: Standard carton
Delivery Time: 7~10 Working days
Payment Terms: L/C, D/P, T/T,
Supply Ability: 10000/Piece/Weekly
Get Best Price Contact Now

Detail Information

Material: Body: Melamine Caps: Copper Alloy (nickel Plated) Rated Current: 60A
Rated Breaking Capacity: 10 KA Rated Voltage: 600V
High Light:

ceramic tube fuse

,

high voltage hrc fuse

Product Description

KLQ Series - 600V 6A Enhanced Time Delay Miniature Fuse High Voltage Fuse

KLQ Series - 600V 6A Enhanced Time Delay Miniature Fuse High Voltage Fuse



KLQ_Datasheet_1.pdf

KLQ_Datasheet_2.pdf





The KLQ series is used to protect steam equipment, HID ballasts and other electronic and lighting circuits.
KLQ is the same size as the BLS, but has a longer delay in response to transient currents and inrush currents.



Features/Benefits

• Ideal for 600 Vac or less systems

• Increased time-Delay



Applications

• Gaseous vapor fixtures

• HID ballasts

• Lighting circuits



Specifications
Voltage Rating 600 Vac or less



Amperage Rating 1, 1 6/10, 2, 3, 5, 6



Interrupting Ratings 10 kA @ rated Vac



Material Body: Melamine
                       Caps: Copper Alloy (nickel plated)



Approvals UL Listed (File: E10480)
                 CSA Certified


Environmental RoHS Compliant



Country of Origin Mexico



Part Numbering System



KLQ Series - 600V 6A Enhanced Time Delay Miniature Fuse High Voltage Fuse 0



Ordering Information



AMP

RATING



AMP

CODE



VOLTAGE

(VAC)



INTERRUPTING

RATING (kA)

CATALOG

NUMBER



ORDERING

NUMBER



UPC

NOM COLD

RESISTANCE

(ohm)



AC
1 001. 600 10 KLQ001 0KLQ001.T 07945805334 1.414
1 6/10 01.6 600 10 KLQ01.6 0KLQ01.6T 07945805335 0.6536
2 002. 600 10 KLQ002 0KLQ002.T 07945805336 0.4
3 003. 600 10 KLQ003 0KLQ003.T 07945805337 0.1829
5 005. 600 10 KLQ005 0KLQ005.T 07945805339 0.0766
6 006. 600 10 KLQ006 0KLQ006.T 07945805340 0.0571



DIMENSIONS (mm)



KLQ Series - 600V 6A Enhanced Time Delay Miniature Fuse High Voltage Fuse 1





FAQ


Q: Can I have a sample order?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q: Can we have our logo or company name to be printed on your products or the package?
A: Yes, for container order, we have OEM packing service, you need to inform us your logo or company information in details. For bulk cargo, we will use neutral packing.
Q: What adventages do you have?
A: Fast delivery and good service.
Stable quality with competitive price.
Strict management system.


Please tell me:
What product specifications do you need? when you ask for a quotation.I will give you the most competitive price per as your requirements. And we have many types for you to choose.


P.S.:If you can't find any products to meet your requirements. welcome to send us the details drawings so that we can provide us our professional & best service to you.
