Cylindrical Cap High Voltage Fuse 30Ma Quick Break Fast Blow Fuse 660v Ac / 660v Dc 6x30mm

China Cylindrical Cap High Voltage Fuse 30Ma  Quick Break Fast Blow Fuse 660v Ac / 660v Dc 6x30mm supplier

Large Image :  Cylindrical Cap High Voltage Fuse 30Ma Quick Break Fast Blow Fuse 660v Ac / 660v Dc 6x30mm

Product Details:

Place of Origin: CHINA
Brand Name: Julun
Certification: CE/UL/VDE/KC/ROHS
Model Number: HV630

Payment & Shipping Terms:

Minimum Order Quantity: 100 / Negotiable
Price: Negotiable
Packaging Details: Standard carton
Delivery Time: 7~10 Working days
Supply Ability: 10000/Piece/Weekly
Contact Now
Detailed Product Description
Rated Voltage: 600VAC/DC Rated Current: 30A
Dimension: 6*30MM Material: Ceramic
Purpose: HVDC / Digital Instrument

660V, 6x30mm, Lead type high voltage fast melting ceramic tube fuse



hv630 series.pdf



Description



 Fast Acting, high breaking capacity under 660V
 6x30mm physical size
 Special Engineering Material tube, Silver plated copper cap construction
 Designed to UL 248-1
 Lead Free material



Electrical Characteristics
Rated Current 1.0In 2.5In
200mA - 30A 4 hour min. 120 sec max.



Specifications



Part No. Rated
Voltage
Rated Current Breaking Capacity (A) Typical Cold. Resistance (mOhms) Typical Voltage Drop (mV) Typical Pre-Arcing I2t (A2Sec)
AC DC AC DC
HV630.0.2 660V 660V 200mA 1000A 1000A 1830 780 0.0031
HV630.0.25 250mA 1760 760 0.009
HV630.0.315 315mA 1700 720 0.05
HV630.0.4 400mA 1650 700 0.059
HV630.0.5 500mA 1000 600 0.081
HV630.0.6 600mA 750 530 0.178
HV630.0.8 800mA 530 500 0.43
HV630.1 1A 450 560 0.21
HV630.1.25 1.25A 260 400 1.37
HV630.1.6 1.6A 180 350 3.72
HV630.2 2A 150 360 1.5
HV630.2.5 2.5A 80 300 4.5
HV630.3 3A 60 270 7.54
HV630.3.15 3.15A 50 250 12.66
HV630.4 4A 40 230 15.8
HV630.5 5A 30 200 30
HV630.6 6A 20 186 84.5
HV630.8 8A 17 175 75
HV630.10 10A 16 170 97.7
HV630.12 12A 8.8 120 148
HV630.12.5 12.5A 8 115 153
HV630.15 15A 7.5 110 158
HV630.16 16A 7 107 162
HV630.20 20A 5.2 105 500
HV630.25 25A 3.5 100 583
HV630.30 30A 3 92 1016



* DC Cold Resistance are measured at <10% of rated current in ambient temperature of 25℃
* Typical Pre-arching I2t are measured at 10In Current



Dimension



Cylindrical Cap High Voltage Fuse 30Ma  Quick Break Fast Blow Fuse 660v Ac / 660v Dc 6x30mm







FAQ


1.Are you a factory or trading company?
We are a factory founded in 2009 and have over 9 years’ OEM and international trading experience

2.What’s your main product?
Our main products are fuse series, resistance series, capacitance series, fuse pedestal series, sensor series

3.Any certification of your company or product?
We have ISO 9001-2008 ,CE(LVD), RoHS, TUV,cURus,VDE,CQC,PSE,KC Certificates and Test Report for these certificate.

4.Which countries have your product been exported to ?
We have exported our product to over 20 countries , such as Russia , India ,Thailand, Indonesia, Malaysia, Tunisia, Brazil ,Iran, U.A.E ,Mexico, Colombia, Venezuela , Argentina etc.

5.Which international exhibition do you usually go to?
China Import and Export Fair (Canton Fair) ELEKTRO , Russia / FIEE ELéTRICA ,Brazil.

6.Can I visit your factory?
We have over 5000 square meters of workspace and sincerely welcome your business visit.

7.Do you accept OEM or ODM?
Of course.

8.How’ your production capacity? How long is the lead time ?
Monthly output 50,000 piece . It usually take us 20-30 days to finish the goods.

9.What’s your main payment term?
T/T ,LC ,D/P.

10.Any quality guarantee or after-sales service?
If any quality complaint , we will give out solution within 5 days.

11.Can sample fee be returned back to me ?
Sample amount can be deducted from your bulk order payment when order quantity is over 1000 pieces at the first time.

12.How many days it takes to finish the samples?
Usually 2-5 work days .


Please tell me:
What product specifications do you need? when you ask for a quotation.I will give you the most competitive price per as your requirements. And we have many types for you to choose.


P.S.:If you can't find any products to meet your requirements. welcome to send us the details drawings so that we can provide us our professional & best service to you.
