Battery Ceramic Automotive 150DC Fuses 200A Copper Silver Quartz Sand Gold Electric current 100A 150A 200A 250A 300A 350A 400A 500A
Product Details:
| Place of Origin: | China |
| Brand Name: | ASTM FUSE BATTERY AUTOMOBILE MOTORCYCEL FUSE |
| Certification: | UL |
| Model Number: | A202001 100A 150A 200A 250A 300A 350A |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 |
|---|---|
| Price: | 4.8USD |
| Packaging Details: | Carton |
| Delivery Time: | 2~4weeks |
| Payment Terms: | T-T |
| Supply Ability: | 1000K/PCS |
|
Detail Information |
|||
| Breaking Capacity: | 20KA(100~350A) 16~20KA 400A 500A | Electrical Characteristics: | 1.0In >4 Hours 3.0In 10s Max. |
|---|---|---|---|
| Application Product: | EV Traction System, Power Conversion, Energy Storage, Car Charger And Etc. | Mounting Method: | SCREW BOLT |
| Hole Distance: | 39mm | Material: | Ceramic Copper Silver Quartz Sand Gold |
| Voltage: | 150VDC | Feature: | Small Size With High Current Rating For Short Circuit Protection |
Product Description
Product Description:
These Ceramic Automobile Fuses have excellent electrical characteristics, with 1.0In >4 Hours and 3.0In 10s Max. This ensures that your car's electrical system is protected from overloading and short-circuiting. These fuses are perfect for use in EV Traction Systems, Power Conversion, Energy Storage, Car Chargers, and other applications.
Our Ceramic Vehicle Fuses are available in a range of electric current options to meet your specific needs. Choose from 100A, 150A, 200A, 250A, 300A, 350A, 400A, and 500A. These fuses are designed to provide maximum protection and reliability for your car's electrical system, ensuring that your vehicle runs smoothly and efficiently.
Trust in the quality and reliability of our Ceramic Automotive Fuses. These fuses are made from high-quality materials and are designed to provide maximum protection and reliability for your car's electrical system. Don't settle for inferior fuses - choose our Ceramic Automobile Fuses for the ultimate protection and peace of mind.
Features:
- Product Name: Ceramic Automotive Fuses
- Hole distance: 39mm
- Breaking capacity: 20KA(100~350A) 16~20KA 400A 500A
- SIZE: 20*55mm
- Installation mode: Recommended Tight Torque: 11-13N·m For M8
- Feature: Small Size With High Current Rating For Short Circuit Protection
- Keywords: Ceramic Automobile Fuses, Ceramic Vehicle Fuses, Ceramic Car Fuses
Technical Parameters:
| Attribute | Value |
|---|---|
| Product Name | Ceramic Automotive Fuses |
| Size | 20*55mm |
| Electrical Characteristics | 1.0In >4 Hours, 3.0In 10s Max. |
| Material | Ceramic, Copper, Silver, Quartz Sand, Gold |
| Application Product | EV Traction System, Power Conversion, Energy Storage, Car Charger And Etc. |
| Feature | Small Size With High Current Rating For Short Circuit Protection |
| Breaking Capacity | 20KA(100~350A), 16~20KA 400A, 500A |
| Hole Distance | 39mm |
| Voltage | 150VDC |
| Mounting Method | SCREW BOLT |
| Electric Current | 100A, 150A, 200A, 250A, 300A, 350A, 400A, 500A |
Applications:
The Ceramic Automotive Fuses are designed to be small in size with a high current rating, making them ideal for short circuit protection. They are mounted using a screw bolt and have a size of 20*55mm. These fuses have a breaking capacity of 20KA for current ratings of 100A to 350A, and 16~20KA for current ratings of 400A and 500A. They have electrical characteristics of 1.0In >4 Hours and 3.0In 10s Max.
The Ceramic Automotive Fuses are suitable for a variety of applications in the automotive and motorcycle industry. They can be used in vehicles such as cars, trucks, motorcycles, and more. These fuses are commonly used in the electrical system of these vehicles for short circuit protection. They are also used in battery circuits, starter circuits, and other high current applications.
The Ceramic Automotive Fuses are available for purchase with a minimum order quantity of 100. The price for these fuses ranges from 1.5~2USD. They are packaged in cartons and have a delivery time of 2~4 weeks. The payment terms for this product are T-T, and the supply ability is 1000K/PCS.
In summary, the ASTM FUSE BATTERY AUTOMOBILE MOTORCYCEL FUSE is a high-quality ceramic car fuse that is suitable for a variety of applications in the automotive and motorcycle industry. With its small size and high current rating, it provides reliable short circuit protection for vehicles. It is available for purchase with a minimum order quantity of 100 and is priced competitively. For those in need of a reliable automotive fuse, the Ceramic Automotive Fuses are an excellent choice.
Customization:
Customize your Ceramic Car Fuses with our product customization services. Our brand name, ASTM FUSE BATTERY AUTOMOBILE MOTORCYCEL FUSE, offers high-quality fuses for your automotive needs. Our model numbers include A202001 100A, 150A, 200A, 250A, 300A, and 350A. Our Ceramic Vehicle Fuses are made in China and are UL certified. The minimum order quantity is 100 pieces, and the price ranges from 1.5 to 2 USD per piece. The packaging details include a carton, and the delivery time is typically 2 to 4 weeks. Payment terms are T-T, and our supply ability is 1000K/pcs.
Our Ceramic Automobile Fuses are easy to install with recommended tight torque of 11-13N·m for M8. The mounting method is a screw bolt, and the hole distance is 39mm. Our fuses can handle electric currents ranging from 100A to 500A and voltage up to 150VDC.
Support and Services:
The Ceramic Automotive Fuses product technical support and services include:
- Expert technical assistance in identifying the right fuse for specific automotive applications
- Assistance in troubleshooting fuse-related issues
- Product documentation and specifications
- Customized fuse design and development services
- Training and educational resources on fuse technology and usage
- Repair and replacement services for defective fuses
