50mA 0.05A 250V 5*20mm Fast Acting Fuse With Ceramic Tube
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | Julun |
| Certification: | CE/UL/VDE/KC/ROHS |
| Model Number: | 611 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 / Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard carton |
| Delivery Time: | 7~10 Working days |
| Payment Terms: | L/C, D/P, T/T, |
| Supply Ability: | 10000/Piece/Weekly |
|
Detail Information |
|||
| Material: | Glass | Dimension: | 6*30mm |
|---|---|---|---|
| Breaking Capacity: | Fast | Rated Voltage: | 250VAC/150VAC |
| High Light: | 50mA Fast Acting Fuse,0.05A Fast Acting Fuse,5*20mm Ceramic Tube Fuse |
||
Product Description
Ceramic Fuse 50mA 0.05A 250V 5X20mm Axial Lead & Cartridge Fuses Fast-Acting Fuse
our service
1. pre sales part selection guide
2. fast acting logistics service through our Hongkong and Shenzhen logistic centers
3. after sales problem shooting service
4. testing and measuring service for all products sold
5. solution for relevant parts based on customers requirment
Products Details Description
| Item | 1A 1.25A 2A 3.15A 6.3A 10A 125V 250V Lead Wire Ceramic Fuse |
| Voltage | 125V 250V |
| Aperes | 100mA, 125mA,160mA, 200mA, 250mA, 315mA, 400mA, 500mA, 630mA, 800mA, 1A, 1.25A 1.6A, 2A 2.5A,3.15A 4A, 5A, 6.3A, 8A, 10A, 12.5A, 16A, 20A, 25A, 31.5A |
| Color | white |
| Material | Body: Ceramic; Wire:Tin-Plated Copper; Fuse element: Alloy; Cap: Nickel Plated Brass |
| Accessories | cap, lead wire. |
| Application | industrial of Lighting, Power supply and Adapter applications,Switching Power Supply, charger, Transformers, Computers, Telephones, Household Household Appliances, Communications Products, Toy Products,etc. |
| Certification | CCC, VDE, PSE |
| Warranty | 1 years |
| Service | OEM & ODM can be accepted |
| Packing | 200pcs/bag, then into paper carton |
| MOQ | 500 piece |
| Loading Ports | Dongguan China |
Main Characteristics
Cartridge miniature fuse; Time-Lag (T)
Materials
Tube: Ceramic
End caps: Nickel-plated brass Axial leads:Nickel-plated caps
Tin-plated copper wires
Operating Temperature
-55°C to +125°C Storage Conditions
+10°C to +60°C
Relative humidity:≤75% yearly average without dew, maximum 30 days at 95%
Vibration Resistance
24 cycles at 15 min. each (60068-6) 10-60Hz at 0.75mm amplitude 60-2000Hz at 10g acceleration
Soldering Parameters
260°C.≤5 sec (Wave Soldering) 350°C.≤3 sec (Hand Soldering) Soldering Peak:
260°C. 10 sec. (IEC 60068-20)
Time vs Current Characteristics: UL 248-14
| Rated Current | 100% | 110% | 115% | 135% | 200% | 210% | 275% | 400% | 1000% |
| 500mA~20A | >4h | / | / | <1h | <10s | / | / | / | / |
| 12.5A/16A(IEC) | / | / | >1h | / | / | <60s | 20ms~3s | 8ms~1s | ≤150ms |
| 15A/20A/25A(PSE) | / | >1.5h | / | <1h | <120s | / | / | / | / |
Electrical properties
| Model | Amp Code | Amp Rating | Voltage Rating(V) | Interrupting Rating | Nominal Cold Resistance (Ohms) | Nominal Melting I2t (A2Sec.) | Nominal Voltage Drop at Rated Current(mV) | Maximum Power Dissipation at 1.5ln(W) | Agency Approvals | |
|
0216.050
|
.050
|
0.05
|
250
|
1500A@250VAC
|
15.9000
|
0.00019
|
10000
|
1.6
|
||
|
0216.063
|
.063
|
0.063
|
250
|
10.4500
|
0.00054
|
8800
|
1.6
|
|||
|
0216.080
|
.080
|
0.080
|
250
|
7.8850
|
0.00084
|
7600
|
1.6
|
|||
|
0216.100
|
.100
|
0.1
|
250
|
5.7925
|
0.00450
|
7000
|
1.6
|
|||
|
0216.125
|
.125
|
0.125
|
250
|
3.6750
|
0.00546
|
5000
|
1.6
|
|||
|
0216.160
|
.160
|
0.16
|
250
|
5.3490
|
0.00576
|
4300
|
1.6
|
|||
|
0216.200
|
.200
|
0.2
|
250
|
3.3500
|
0.00439
|
3500
|
1.6
|
|||
|
0216.250
|
.250
|
0.25
|
250
|
2.3500
|
0.00891
|
2800
|
2.5
|
|||
|
0216.315
|
.315
|
0.315
|
250
|
1.8500
|
0.01000
|
2500
|
2.5
|
|||
|
0216.500
|
.500
|
0.5
|
250
|
0.8660
|
0.16500
|
1800
|
2.5
|
|||
|
0216.630
|
.630
|
0.63
|
250
|
0.4650
|
0.17500
|
1500
|
2.5
|
|||
|
0216.800
|
.800
|
0.8
|
250
|
0.2950
|
0.28500
|
1200
|
2.5
|
|||
|
0216001.
|
001.
|
1
|
250
|
0.2370
|
0.18000
|
1000
|
2.5
|
|||
|
02161.25
|
1.25
|
1.25
|
250
|
0.1530
|
0.48000
|
800
|
4
|
|||
|
021601.6
|
01.6
|
1.6
|
250
|
0.1112
|
1.00500
|
600
|
4
|
|||
|
0216002.
|
002.
|
2
|
250
|
0.0764
|
1.87000
|
500
|
4
|
|||
|
021602.5
|
02.5
|
2.5
|
250
|
0.0584
|
2.69500
|
400
|
4
|
|||
|
02163.15
|
3.15
|
3.15
|
250
|
0.0368
|
6.70000
|
350
|
4
|
|||
|
0216004.
|
004.
|
4
|
250
|
0.0247
|
14.99500
|
300
|
4
|
|||
|
0216005.
|
005.
|
5
|
250
|
0.0183
|
27.46000
|
250
|
4
|
|||
|
021606.3
|
06.3
|
6.3
|
250
|
0.0137
|
56.43000
|
200
|
4
|
|||
|
0216008.
|
008.
|
8
|
250
|
0.0123
|
64.31500
|
200
|
4
|
|||
|
0216010.
|
010.
|
10
|
250
|
0.0079
|
154.34000
|
200
|
4
|
|||
|
021612.5
|
12.5
|
12.5
|
250
|
0.0057
|
235.00000
|
200
|
4
|
|||
|
0216016.
|
016.
|
16
|
250
|
750A@250VAC
|
0.0040
|
462.50000
|
200
|
4.5
|
||
Note: (1) Permissible continuous operating current is ≤100% at ambient temperature of 23°C (73.4°F)
(2) The cURus and cULus certification by 125V and 250V; the CQC certification by 250V;
the PSE certification by 125V
