TO-220AC Transient Voltage Suppressor Diode  10.0Amp Schottky Barrier Rectifiers

TO-220AC Transient Voltage Suppressor Diode 10.0Amp Schottky Barrier Rectifiers

Product Details:

Place of Origin: CHINA
Brand Name: Julun
Certification: CE/UL/VDE/KC/ROHS
Model Number: TO-220AC

Payment & Shipping Terms:

Minimum Order Quantity: 100 / Negotiable
Price: Negotiable
Packaging Details: Standard carton
Delivery Time: 7~10 Working days
Payment Terms: L/C, D/P, T/T,
Supply Ability: 10000/Piece/Weekly
Get Best Price Contact Now

Detail Information

Case: (I)TO-220AB,TO-263,TO-252 Molded Plastic Body Terminals: Solder Plated, Solderable Per MIL-STD-750
Polarity: As Marked Mounting Position: Any
High Light:

tvs protection diode

,

schottky barrier diode

Product Description

TO-220AC Transient Voltage Suppressor Diode 10.0Amp Schottky Barrier Rectifiers

10.0Amp Schottky Barrier Rectifiers



Features

The plastic package carries Underwriters Laboratory

Flammability Classification 94V-0

Construction utilizes void-free molded plastic technique

Low reverse leakage

High forward surge current capability

High temperature soldering guaranteed: 250°C,MAX. for 10 seconds



Mechanical Data

Case : (I)TO-220AB,TO-263,TO-252 molded plastic body

Terminals: Solder plated, solderable per MIL-STD-750, Method 2026

Polarity : As marked

Mounting Position : Any



Maximum Ratings And Electrical Characteristics

Ratings at 25TO-220AC Transient Voltage Suppressor Diode  10.0Amp Schottky Barrier Rectifiers 0C ambient temperature unless otherwise specified. Single phase half-wave 60Hz,resistive or inductive load, for capacitive load current derate by 20%.



  SYMBOLS

MBR
1020

(F)CT

MBR
1040

(F)CT

MBR
1045

(F)CT

MBR
1060

(F)CT

MBR
10100

(F)CT

MBR
10150

(F)CT

MBR
10200

(F)CT

UNITS
Maximum repetitive peak reverse voltage VRRM 20 40 45 60 100 150 200 VOLTS
Maximum RMS voltage VRMS 14 28 32 42 70 105 140 VOLTS
Maximum DC blocking voltage VDC 20 40 45 60 100 150 200 VOLTS
Maximum average forward rectified current
(see fig.1)
I(AV) 10 Amps
Peak forward surge current
8.3ms single half sine-wave superimposed on
rated load (JEDEC Method)
IFSM 150 Amps
Maximum instantaneous forward voltage at 5.0A VF 0.55 0.6 0.7 0.85 0.95 Volts
Maximum DC reverse current TA=25 C
at rated DC blocking voltage TA=100 C
IR 0.15 0.1 ma
40 20
Typical junction capacitance (NOTE 1) CJ 550 150 pF
Typical thermal resistance (NOTE 2) RqJC 28 C/W
Operating junction temperature range TJ -55 to +125 -55 to +150 C
Storage temperature range TSTG -55 to +150 C



Note:1.Measured at 1MHz and applied reverse voltage of 4.0V D.C.



2.Thermal resistance from junction to case



TO-220AC Transient Voltage Suppressor Diode  10.0Amp Schottky Barrier Rectifiers 1
